Old November 27th, 2012, 05:23 PM   #16
Dodgin' The Reaper

hammonje's Avatar

Join Date: Sep 2007
Location: Lilburn, GA
Posts: 6,532
Yep...one more to go for 16. One for each man in my home defense platoon!!!!!!! I want my house to look like the USS Missouri with so many barrels hanging out the windows. The USS Hammonje.

Come and get 'em BLUE HATS!!!!!!!

All kidding aside...the fun part remains. Some serious trigger time and tweaking to get the most accuracy out of them. These, unfortunately, will have to get in line.

Thanks from sjstill

Last edited by hammonje; November 27th, 2012 at 05:34 PM.
hammonje is offline
Remove Ads
Old November 27th, 2012, 05:29 PM   #17
Automatic Rifleman

meterman's Avatar

Join Date: Nov 2012
Location: young harris Ga.
Posts: 132
awesome looking guns man REAL nice

Thanks from hammonje
meterman is offline
Old November 27th, 2012, 05:55 PM   #18
Lifer

Bamban's Avatar

Join Date: Oct 2006
Location: Austin, TX
Posts: 3,926

Awards Showcase

Nice builds. What tools do you use to properly index the barrels?

Thanks from hammonje
Bamban is offline
Old November 27th, 2012, 06:18 PM   #19
Lifer

boomer1983's Avatar

Join Date: Nov 2010
Location: Denver, Colorado
Posts: 2,109
Quote:
Originally Posted by hammonje View Post
Yep...one more to go for 16. One for each man in my home defense platoon!!!!!!! I want my house to look like the USS Missouri with so many barrels hanging out the windows. The USS Hammonje.

Come and get 'em BLUE HATS!!!!!!!

All kidding aside...the fun part remains. Some serious trigger time and tweaking to get the most accuracy out of them. These, unfortunately, will have to get in line.
ha! thats hilarioud, uss hammonje. good stuff!

Thanks from hammonje
boomer1983 is offline
Old November 27th, 2012, 06:49 PM   #20
Dodgin' The Reaper

hammonje's Avatar

Join Date: Sep 2007
Location: Lilburn, GA
Posts: 6,532
Quote:
Originally Posted by Bamban View Post
Nice builds. What tools do you use to properly index the barrels?
To index my barrels, I originally used magnetic angle finders and the receiver flat behind the rear sight and the top of the flash hider sight dovetail. Not the best procedure, but it does work. Tends to under index the barrels in my hands.

On Art's (nf1e), 82nd AB, and others suggestions I bought the Badger Ordnance Receiver/Barrel Timing Gages from Brownell's together with a Harbor Freight Digital Angle Finder. I now get my indexing down to less than 0.3 degrees or the error of the digital angle finder. I also check to confirm with a Starrett 135A bubble level, so I get it down to basically 0.1 degree of variance. The Starrett bubble level is my final confirmation and I get it matched perfectly. This was a suggestion and method employed by Lapriester on the CMP Forum. I got this check from him.

Then it's time to finish ream or check headspace if using USGI chrome-lined barrel as these are. I finish ream using .308 Win Manson reamers and pull through with a Starrett tap handle.

I hope my instructions were clear and comprehensible.

Brownells Badger Ordnance Timing Gauges Set: $72
http://www.brownells.com/gunsmith-to...5088-5308.aspx

Digital Angle Finder: $30
http://www.harborfreight.com/digital...uge-95998.html

Starrett 135A bubble level: $25
http://www.amazon.com/Starrett-135A-.../dp/B0002FS0XM

Thanks from Bamban
hammonje is offline
Old November 27th, 2012, 07:02 PM   #21
Platoon Commander

mariodesmo's Avatar

Join Date: Jun 2011
Location: SF Bay Area, Ca
Posts: 538
Quote:
Originally Posted by hammonje View Post
... I want my house to look like the USS Missouri with so many barrels hanging out the windows. The USS Hammonje.

Come and get 'em BLUE HATS!!!!!!!
Here ya go!

The guns are not normally in the upright (ready to fire) position but at the time I took the picture, they were filming Pear Harbor, the movie.

Good Luck!

mariodesmo is offline
Old November 27th, 2012, 07:31 PM   #22
Old Salt

Quicksilvergoat's Avatar

Join Date: Aug 2011
Location: ST MinnePaulis
Posts: 1,769
I miss my parts. Lol. The funny thing is I saw my old GTO on Craigslist this week. I wonder if I check out some porn sites maybe an old girlfriend or two will show up.

Thanks from hammonje
Quicksilvergoat is online now
Old November 27th, 2012, 08:13 PM   #23
Lifer

Bamban's Avatar

Join Date: Oct 2006
Location: Austin, TX
Posts: 3,926

Awards Showcase

Quote:
Originally Posted by hammonje View Post
To index my barrels, I originally used magnetic angle finders and the receiver flat behind the rear sight and the top of the flash hider sight dovetail. Not the best procedure, but it does work. Tends to under index the barrels in my hands.

On Art's (nf1e), 82nd AB, and others suggestions I bought the Badger Ordnance Receiver/Barrel Timing Gages from Brownell's together with a Harbor Freight Digital Angle Finder. I now get my indexing down to less than 0.3 degrees or the error of the digital angle finder. I also check to confirm with a Starrett 135A bubble level, so I get it down to basically 0.1 degree of variance. The Starrett bubble level is my final confirmation and I get it matched perfectly. This was a suggestion and method employed by Lapriester on the CMP Forum. I got this check from him.

Then it's time to finish ream or check headspace if using USGI chrome-lined barrel as these are. I finish ream using .308 Win Manson reamers and pull through with a Starrett tap handle.

I hope my instructions were clear and comprehensible.

Brownells Badger Ordnance Timing Gauges Set: $72
http://www.brownells.com/gunsmith-to...5088-5308.aspx

Digital Angle Finder: $30
http://www.harborfreight.com/digital...uge-95998.html

Starrett 135A bubble level: $25
http://www.amazon.com/Starrett-135A-.../dp/B0002FS0XM
Thank you for the info.
